20000Psi Hydro Jetting Equipment For Large Tube Automatic Cleaning



The 1400bar 100L/min large tube automatic cleaning Hydro Jetting Equipment combines extremely high working pressure and large flow rate, and can powerfully remove all kinds of stubborn dirt, such as oil stains, mud, rust, etc., and is especially suitable for cleaning hard-to-reach or complex surfaces. Suitable for cleaning large industrial pipelines and petrochemical pipelines. Equipped with an automatic pipeline crawler, it can realize automatic cleaning inside the pipeline of 800-1500mm.



The 20500psi Large Tube Cleaning Hydro Jetting Equpment can efficiently and quickly clean various hard-to-clean hard scales in large industrial pipelines. According to the size of the inner diameter of the pipeline, we support the customization of various specifications of pipeline automatic crawlers to meet the requirements of automatic cleaning of large industrial pipelines. There is no need for manual handheld high-pressure gun cleaning, which saves manpower.



Large industrial pipe cleaning hydro blasting machine is a method of cleaning verious large industrial pipes. It uses high-pressure water flow through a special jet nozzle to clear and remove obstructions, and performs regular maintenance to prevent sewage back flow.



Large industrial tube cleaning hydro blasting machine use high pressure water to clean tubes and tanks, and can also protect coatings, old paint, epoxy resin, rust removal.



Hydro jetting machine uses water at pressures of 100 bar to 300 bar to clean the inside of drains and sewer pipes. Using 3D nozzles, it can also be used for hull paint and rust removal.



This method is ideal for internal and external surface cleaning because the water jet operator is able to reach those "hard to reach" areas. In addition, due to its powerful water spraying power, the user can maintain a safe distance from the surface being cleaned.



Large industrial pipe cleaning hydro blasting machines are essential to maintaining the cleanliness and integrity of tanks and pipes in industries such as oil and gas, chemical processing, food and beverage, and wastewater treatment. By effectively removing deposits and contaminants, these machines help prevent blockages, corrosion, and other issues that can affect the efficiency and safety of industrial operations.

key features and functions

High-pressure water jets: The machine typically utilizes a high-pressure water jet to remove and dislodge stubborn deposits and buildup from the surface of a tank or pipe. It directs a powerful stream of water at high pressure to effectively clean and flush away contaminants.

Rotating nozzles or cleaning heads: Cleaning machines typically contain rotating nozzles or cleaning heads that can be inserted into the pipe. These rotating nozzles ensure thorough coverage and provide 360-degree cleaning, reaching all areas of the surface.

Water recovery and filtration: To optimize water usage and minimize environmental impact, some cleaning machines may contain water recovery and filtration systems. These systems filter and reuse water, reducing the amount of fresh water required for the cleaning process.

Remote operation and monitoring: Depending on the design and sophistication of the machine, it may offer remote operation and monitoring capabilities. This enables the operator to control the cleaning process from a safe distance and monitor the progress of the cleaning operation.

Adjustable pressure and flow: The machine typically allows the operator to adjust the pressure and flow of the water jet to meet different cleaning requirements. This flexibility ensures that the cleaning process can be customized to the specific nature of the deposits as well as the condition of the pipe.

We can customize different specifications of pipeline crawlers for this large pipeline cleaning high-pressure jetting machine according to the inner diameter of the customer's pipeline. Inside the pipeline, the pipeline crawler automatically crawls forward under the force of high-pressure water. The crawler is equipped with a 3D rotating nozzle, which can achieve 360-degree cleaning inside the pipeline and effectively remove stains inside the pipeline.





Model	GYB-5 1400/100
Pump Speed	366 rpm
High pressure pump	Triple plunger pump
	Pump head material: Stainelss steel
	Plunger material: stainless steel
	Pump speed:366rpm
	Plunger stock:120mm
Rate Pressure	1400 bar / 20500 psi
Water flow	100 L/min
Plunger dia.	22mm
Electric motor drive	160kw, 3Phase, 380v/50Hz or 440v/60Hz
Diesel engine drive	225kw, 6-cylinder







Industrial and sewer PIpe cleaning

Pipe pressure test, valve / hose pressure test, hydro pressure test, etc

Heavy equipment cleaning

Construction industry, car/truck cleaning, mixing drum/tank cleaning, tar/cement/agglutinant cleaning, etc

Ship and deck cleaning

Ship yard rust removal, paint removal, ship hull cleaning, boat surface cleaning, dirt removal, sea creatures remove from the hull bottom.

Rust remove

Cement plant pipe cleaning, grease remove from the equipment surface, fouling layer removal.

Exchanger cleaning

heat exchanger tube cleaning, condenser tube cleaning, pipe cleaning, reactor tank cleaning, filter screen cleaning, boil cleaning, tank cleaning, etc.











1. Packing: Plywood packing

2. Shipping way: suggest deliver by sea

3. Delivery port: Qingdao Port; or deliver to any port you need
